You can also right-click the Mesh cell to display the context menu where you can select the edit. This displays the ANSYS Meshing application with the elbow geometry already loaded. In the ANSYS Workbench Project Schematic, double-click the Mesh cell in the elbow fluid flow analysis system. View the list of files generated by workbench by selecting:.
Close ANSYS Design Modeler by selecting:įile → Close Design Modeler or by clicking the ‘X’ icon in the upper right-hand corner.ĪNSYS Workbench automatically saves the geometry and updates the Project Schematic accordingly.It is often important to predict the flow field and temperature field in the area of the mixing region in order to properly design the junction. The mixing elbow configuration is encountered in piping systems in power plants and process industries. A cold fluid at 293.15 K flows into the pipe through a large inlet and mixes with a warmer fluid at 313.15 K that enters through a smaller inlet located at the elbow. The problem is shown schematically in the figure below. Task: Gain basic knowledge of how to work with Ansys Fluent module by example from the problem shown below.
